Axial rolling systems with roll holders, stationary
Axial rolling system RS60-5 stationary
| Weight |
28 kg |
| Working range Ø (mm/inch) |
32–60 / 1.26–2.244 |
| Pitch max. (mm/inch) |
3 / 8 t.p.i. |
Shank-Ø D
(mm/inch) |
d (mm) |
L (mm) |
LS (mm)
(mm) |
L1 (mm) |
L3 (mm) |
| 40 |
- |
133.8 |
80 |
100 |
39 |
| VDI 40 |
- |
148.8 |
63 |
123 |
54 |
| VDI 50 |
- |
148.8 |
78 |
123 |
54 |
